YRi-V High Speed, High Resolution 3D Optical Inspection System
3D
Inspections
8-way
projector
4
Angle
Angle
20 Megapixels
Super
High-resolution
Features
Super high-speed 3D inspections 56.8cm²/sec (under optimum conditions)
Super high-accuracy 3D inspections 8-way projector
4-way oblique imaging inspections 20Megapixels 4-angle camera
Device inspections Super high-resolution 5μm/coaxial lighting
Specifications
| Number of Camera Pixels | 12 Megapixel | 25 Megapixel | |||
|---|---|---|---|---|---|
| Resolution | 12μm | 7μm | 5μm | ||
| FOV | 50 x 37.5mm | 50 x 35.85mm | 50 x 25.6mm | ||
| 2D Lighting | |||||
| 3D Projector | |||||
| 3D Laser | - | Optional | |||
| 3D inspection height | Max. 25mm ※ Higher values of focus depth improve 3D shape reproduction of higher parts. | ||||
| Focus depth | 14mm | 8mm | 4mm | ||
| Speed | 56.8 cm2/s | 30.5 cm2/s | 16.2 cm2/s | ||
| 4-way camera | |||||
| PCB Size | |||||
